Main technical parameters of the drive
model | Rated voltage | power | Drive mode | Working time with SRV2000 valve | net weight(kg) |
VA7010-220 VA7010-110 | AC220V±10% | 7W | One-way motor drive Valve spring reset | Full open time: about 10 seconds after power on Closing time: about 5 seconds after power off | 0.3 |
AC110V±10% | |||||
VA7010-24 | AC24V±10% |
Main technical parameters of copper valve
Product number | Valve form | Connecting thread | Flow CoefficientKv | Close pressure difference(MPa) | jobs medium | fluid temperature | Ambient temperature | Storage temperature | Pressure(MPa) |
VA7010-15 | Normally closed two-way valve | G1/2 | 1.5 | 0.25 | Frozen/hot water | 2-94℃ | 0-60℃ | -20-65℃ | 1.6 |
VA7010-15 | Mixed three-way valve | G1/2 | 1.5 | 0.25 | |||||
VA7010-20 | Normally closed two-way valve | G3/4 | 2.5 | 0.1 | |||||
VA7010-20 | Mixed three-way valve | G3/4 | 2.5 | 0.1 | |||||
VA7010-25 | Normally closed two-way valve | G1 | 4.8 | 0.06 | |||||
VA7010-25 | Mixed three-way valve | G1 | 4.8 | 0.06 |
